Generador de rampa con integrador (CIR22395S)

Written by: Newton C. Braga
Category: Banco de circuitos



Este circuito usa un integrador de retroalimentación. Lo encontramos en el manual de transistores de Ferranti de 1974. Los transistores son tipos de propósito general en ese momento.



Generador de rampa con integrador
Generador de rampa con integrador
