Astable 4047 (CIR20926S)

Written by: Newton C. Braga
Category: Banco de circuitos



Este circuito se encontró en documentación antigua. La frecuencia depende de R1 y C1. Para los componentes utilizados, la frecuencia está en el rango de unos pocos cientos de kilohertz.



Astable 4047
