Control de corriente para fototransistor 3 (CIR19593S)

Written by: Newton C. Braga
Category: Banco de circuitos



La corriente de este circuito está determinada por un transistor PNP. Texas Instruments sugiere el circuito en una documentación de optoelectrónica. La tensión de alimentación depende de la aplicación.



Control de corriente para fototransistor 3
Control de corriente para fototransistor 3
