Mezclador de video (CIR16470S)

Written by: Newton C. Braga
Category: Banco de circuitos



Encontrado en una Elektor Electronics, este circuito está diseñado para mezclar señales de video analógicas. El circuito tiene una banda de paso de 25 MHz.
