Receptor RCA 8BBT 8 (CIR6062S)

Written by: Newton C. Braga
Category: Banco de circuitos



    Esta radio comercial transistorizada fue fabricada por la RCA en los años 60. El circuito tiene sólo 4 transistores y es alimentado por una tensión de 9 V con una potencia de audio de 20 mW. El receptor es para el rango de ondas medias.




| Haga click en la imagen para ampliar |
